1.5″ Tri-Clamp Stainless Steel Braided Hose
These chemically resistant PTFE braided hoses are a necessity when dealing with harsh chemicals or solvents and high-pressure applications. They provide a uniquely rugged, durable, and chemically resistant combination of Stainless Steel and PTFE. The inner core is corrugated PTFE to optimize the flexibility, protected by a braided stainless steel outer sleeve. These hoses have 1.5″ Tri Clamp flanges on each end.
***Note: Do not exceed the specified hose bend radius or the inner PTFE liner will kink and the hose integrity will become compromised and should not be used. The 24″ version can only bend 90 degrees.
Specifications:
| Connection Type(s): | 1.5″ Tri-Clamp |
| Liner Material | PTFE (Teflon) |
| Braid Material | 304 Stainless Steel |
| Flange Material | 304 Stainless Steel |
| Temperature Rating | -65° to 450°F |
| Pressure Rating | 580 PSI |
| Chemical Resistance | Excellent |
| Bend Radius |
(24″ Length) 13″ (48″, 72″, 96″ Length) 5.5″ |
